★ 50kHz inverter frequency, good x-ray quality, low dose, world top-level technology.
★Thermal capacity 500KJ, long time continuous exposing.
★ With digital closed loop control technology and fault alarm function
2. Exposure Controller
★ Hand controller -- wired exposure
★ Microwave controller -- wireless remote, within 10 meters
3. Flat Panel Detector
★ Whole-plate non-spliced, cesium iodide + amorphous silicon flat-panel detectors
derive from the world's leading technology, which greatly improves performance.
★ Version Scope: 14”x 17”
★ Spatial resolution: 3.7Lp/mm
★ Pixel size: 150μm
★ Output gray scale: 16bit
4. Self Balance Function
★ The support arm can stop at any position,that's our self balance technology, easy operation.
5. Networked device: high quality image and output information system
★ The networking functions of PLX5100 include: Dicom storage, Dicom film printing,Dicom film transfer.
★ It has standard DICOM 3.0 interface, supporting film printing, output, storage, barrier-free docking hospital PACS system.
Technical specifications
|
Properties |
Medical X-ray Equipments & Accessories |
|
Generator output |
5.0 kW |
|
kV range |
40 kV - 120 kV in 1kv steps |
|
mA range |
25~100 mA |
|
Exposure time |
4 films per min |
|
X-ray tube |
1.5*1.5 mm |
|
power supply |
50 Hz |
|
Spatial resolution |
3.7Lp/mm |
|
Pixel size |
150μm |
|
Output gray scale |
14bit |
